Li/S0CL2 Military Packs

Li/S0CL2 Military Packs products

Primary lithium battery packs designed for long-duration military and security applications including covert operations, homeland security, and surveillance systems.
Available in 1/3 M1, 2/3 M1, and M1 configurations with nominal voltages of 11–12V, capacities from 80Ah to 238Ah, and energy ratings from 920Wh to 2,737Wh.
Rugged moulded ABS housings with military-grade Amphenol connectors provide reliable operation in demanding environments.
Operating temperatures up to +55°C and storage temperatures from -32°C to +70°C, depending on pack configuration.
ECCN 3A611.x export license required before export from the U.S. (contact us for further details).

Voltage (Range)

11V-12V

Capacity (Range)

80Ah – 238Ah

Energy (Range)

920Wh – 2,737Wh

Weight (Range)

3.3kg – 10kg

Product	Nominal Voltage	Rated Capacity	Rated Energy	Weight	Size	Tech Data Sheet
CS0032	11-12V	80Ah	920Wh	3.3kg	1/3 M1	CS0032 TDS
CS0033	11-12V	160Ah	1,840Wh	6.7kg	2/3 M1	CS0033 TDS
CS0034	11-12V	238Ah	2,737Wh	10kg	M1	CS0034 TDS
