Lithium Bromine Chloride (Li/BCX) Electrochem Cells

Maximum Pulse Performance. Proven Under Pressure.

Lithium Bromine Chloride (Li/BCX) Electrochem Cells productsUltralife’s Lithium Bromine Chloride (Li/BCX) Electrochem cells are engineered for applications requiring exceptional pulse capability, high-rate performance, and dependable operation in extreme environments. Utilizing advanced spiral-wound construction and proprietary electrolyte technology, these cells deliver the power, responsiveness, and reliability needed for critical applications.

Product Nominal Voltage Rated Capacity Rated Energy Weight Size Note Tech Data Sheet
3B0027 3.9V 1.6Ah 6.2Wh 15g AA size High Rate – BCX85 3B0027 TDS
3B0064 3.9V 1.9Ah 7.4Wh 17g AA size High Rate – BCX85 3B0064 TDS
3B0068 3.9V 3.5Ah 13.7Wh 34g 1/2C size High Rate – BCX85 3B0068 TDS
3B0070 3.9V 7.1Ah 27.7Wh 52g C size High Rate – BCX85 3B0070 TDS
3B3800 3.9V 6.5Ah 25.4Wh 52g C size High Rate – BCX85 3B3800 TDS
3B0075 / 3B4000 3.9V 14Ah 54.6Wh 116g / 111g D size High Rate – BCX85 3B0075 TDS / 3B4000 TDS
3B0076 3.9V 30Ah 117Wh 213g DD size High Rate – BCX85 3B0076 TDS
3B4700 3.9V 31Ah 120.9Wh 200g SD size High Rate – BCX85 3B4700 TDS
3B6050 3.9V 1Ah 3.7Wh 10g Coin Low Rate – BCX85 3B6050 TDS
3B6100 3.9V 38Ah 148.2Wh 290g TSD size High Rate – BCX85 3B6100 TDS
